Durbal WLK30-60-500 Stainless Steel Spherical Plain Bearing 30x70x37mm
Durbal WLK30-60-500 Stainless Steel Spherical Plain Bearing 30x70x37mm
Out of stock
Share this product
Description
Description
DURBAL Heavy-Duty Stainless Steel Spherical Bearings with Integral Self-Aligning Ball Bearing: These spherical bearings are made from hardened and super-finished stainless steel. For high speeds, wide swivelling angles or rotating movements. These bearings have low bearing friction. Low maintenance due to long-term lubrication with food-grade approval. Covering discs in stainless steel on both sides to prevent the penetration of coarse dirt particles inside the bearing. Temperature range: -45 deg C to +120 deg C.
- Brand / Quality:
- Durbal - High Quality
- Inside Diameter:
- 30mm
Technical
Technical
| d | 30mm |
|---|---|
| D | 70mm |
| B | 37mm |
| C | 25mm |
| d1 | 34.5mm |
| tilt angle α | 7.5 deg |
| weight | 0.69kg |
| rotational speed limit n max | 450 min-1 |
| Axial Factor Y | 2.24 Y0 |
| Axial Factor Y0 | 2.35 Y0 |
| basic load rating dyn C | 9.94 kN |
| basic load rating stat Co | 5.25 kN |
| radial clearance CN | 10-30 µm |
