SKU: TSML40C-ISB
ISB TSML40C Left Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M40 Thread
ISB TSML40C Left Hand Maintenance Free Steel/PTFE Lined Plain Female Rod End M40 Thread
Equivalent to: TSML40C
Out of stock
Share this product
Description
Description
TSF - TSM Series Rod End Bearings:: This series is constructed with C 45 improved and forged steel; the surfaces are protected from external corrosive agents, thanks to a galvanised zinc covering. They are available with internal and external threading, to the right and the left and they are provided with greasers or bores for lubrication.
- Brand / Quality:
- ISB-Good Quality
- Thread Size:
- M42x2
- Thread M / F:
- Male
- Thread Direction:
- Left Hand
- Bore:
- 40
- Inside Diameter:
- 40
- Material:
- Steel/PTFE Lined
Technical
Technical
| d | 40mm |
|---|---|
| d2 | 91mm |
| d3 | M42x2mm |
| dk | 66.67mm |
| B | 49mm |
| C1 | 33mm |
| h1 | 150mm |
| I3 | 90mm |
| I4 | 195.5mm |
| α | 17° |
| r 1s min | 0.3mm |
| Weight | 2.3Kg |
