SKF PFD1-1/2TR Square Cast Housing with Grub Screw 1-1/2 inch Insert
SKF PFD1-1/2TR Square Cast Housing with Grub Screw 1-1/2 inch Insert
Out of stock
Description
Description
| SKF Triangular Flanged Y-bearing Units with Pressed Steel Housing and Grub Screws: These units are designed for simple applications with limited loads and speeds. These triangular flanged housings are made of pressed steel and have three square holes for attachment bolts. |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 38.1mm = 1.5 (1-1/2) inch
- Style:
- PFD
- Bolt Hole Centres:
- 119mm
Technical
Technical
| d | 1-1/2 inch |
|---|---|
| A1 | 3.5mm |
| A2 | 10mm |
| B | 49.2mm |
| Da | 91mm |
| H | 146mm |
| H1/L | 53mm |
| J | 119mm |
| N | 13.5mm |
| G | 12mm |
| T | 33.7mm |
| Static load Cr | 19 kN |
| Dynamic load Cor | 30.7 kN |
| Fatigue load limit | 0.8 kN |
| Permissible housing load radial | 7.5 kN |
| Weight | 1.06 kg |
| Housing | PFD80 |
| Insert | YAR208-108-2RF |
