SKU: NNCL4928CV-SKF
SKF NNCL4928CV Double Row Full Complement Cylindrical Roller Bearing 140x190x50mm
SKF NNCL4928CV Double Row Full Complement Cylindrical Roller Bearing 140x190x50mm
Out of stock
Share this product
Description
Description
|
SKF NNCF Series Double Row Full Complement Cylindrical Roller Bearings: Have integral locating flanges on the inner race and one on the outer raceway serving to permit axial location in one direction, a retaining ring is fitted opposite the integral flange to maintain the assembly. They can tolerate axial loads in one direction. Benefits: Tolerate axial load in one direction, none separable construction |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 140mm
- Outside Diameter:
- 190mm
- Width:
- 50mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d | 140mm |
|---|---|
| D | 190mm |
| B | 50mm |
| Dynamic load C | 286 Kn |
| Static load Co | 570 Kn |
| Fatigue load limit Pu | 63 Kn |
| Reference speed | 1500 rpm |
| Limiting speed | 1900 rpm |
| Weight | 4.1 kg |
| d1 | 160mm |
| E | 175.9mm |
| b1 | 6mm |
| K | 3.5mm |
| r1r2 min | 1.5mm |
| S | 4mm |
| da min | 147mm |
| Da max | 183mm |
| Ra max | 1.5mm |
