SKU: C2207KV-SKF

SKF C2207KV Carb Toroidal Roller Bearing with Taper Bore 35x72x23mm Allow 7-10 Days

Name: SKF C2207KV Carb Toroidal Roller Bearing with Taper Bore 35x72x23mm Allow 7-10 Days
Brand: SKF
SKU: C2207KV-SKF
Availability: OutOfStock

Out of stock

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance.
Benefits: High radial and axial loads, misalignment, taper and parallel bore options

Brand / Quality:: SKF - High Quality
Inside Diameter:: 35mm
Outside Diameter:: 72mm
Width:: 23mm
Seals / Shields:: None

Technical

---	Dimensions
d	35mm
D	72mm
B	23mm
d2	44.8mm
D1	60.7mm
r1r2 min	1.1mm
s1	5.7mm
s2	2.7mm
da min	42mm
da max	57mm
Da max	65mm
ra max	1mm
---	Speeds and Loads
Dynamic load C	95 kN
Static load Co	96.5 kN
Fatigue load limit Pu	11.2 kN
Limiting speed	5000 rpm
---	Factors
Misalignment factor k1	0.094
Operating clearance factor k2	0.121
---	Weights
Weight	0.45 kg
---	Matching Adaptor Sleeves
Sleeve No.	<a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H307E+sleeve>H307E</a>
