SKU: BB-624-A500-70-ES
xiros xirodur BB624A50070ES Open Type Polymer Ball Bearing with PEEK Cage and Stainless Steel Balls 4x13x5mm - Allow 2-3 Days
xiros xirodur BB624A50070ES Open Type Polymer Ball Bearing with PEEK Cage and Stainless Steel Balls 4x13x5mm - Allow 2-3 Days
Out of stock
Description
Description
|
IGUS xiros® xirodur® A500 Polymer Ball Bearings: These open type radial deep groove ball bearings consist of PEEK cages and stainless steel balls. The inner rings, outer rings and cages of these bearings are made of FDA-compliant plastics making these bearings suitable for use in the food industry. These bearings are suitable for high temperatures up to +150 deg C. Benefits: Made of FDA approved plastics, lubrication- and maintenance-free, corrosion-resistant, non-magnetic, washable, lightweight, high-temperature range, life time predictable. |
- Brand / Quality:
- Igus - High Quality
- Inside Diameter:
- 4mm
- Outside Diameter:
- 13mm
- Width:
- 5mm
- Seals / Shields:
- None
- Clearance:
- * Standard
- Temperature Range:
- High Temp
Technical
Technical
| d1 | 4mm |
|---|---|
| d2 | 13mm |
| b1 | 5mm |
| Max static axial load | 56 N |
| Static load capacity | 40 N |
| Dynamic load capacity | 52 N |
| Max speed | 4550 rpm |
| Race | A500 |
| Cage | PEEK |
| Ball material | Stainless Steel |
