SKU: UCPW207
UCPW207 Metric Cast Iron Two Bolt Pillow / Plummer Block Housing with 35mm Insert
- Regular price
- $26.18 ex VAT
- Sale price
- $26.18
- Regular price
-
In stock
Quantity Price Breaks
10+
$23.30
19+
$21.99
29+
$21.73
39+
$21.47
49+
$21.21
74+
$20.94
99+
$19.64
199+
$19.37
249+
$19.11
499+
$18.85
999+
$18.33
SKU:
UCPW207
UCPW207 Metric Cast Iron Two Bolt Pillow / Plummer Block Housing with 35mm Insert
- Regular price
- $26.18 ex VAT
- Sale price
- $26.18
- Regular price
-
Description
UCPW200 Series Normal Duty 2 Bolt Pillow Block Housings with Setscrews: These bearing units are supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has a wide inner ring and 2 grub screws to allow tightening against the shaft once fitted. The inserts can be removed from the housing for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
Technical
| d | = | 35mm |
| h | = | 95mm |
| a | = | 166mm |
| e | = | 127mm |
| b | = | 60mm |
| s1 | = | 17mm |
| s2 | = | 21mm |
| g | = | 18mm |
| w | = | 140mm |
| B | = | 42.9mm |
| n | = | 17.5mm |
| Bolt size | = | M14 |
| Bearing no | = | UC207 |
| Housing no | = | PW207 |
| Weight | = | 1.83 kg |
