SKU: UCHA207-21
UCHA207-21 Imperial Cast Iron Hanger Bearing Unit with 1-5/16 inch Bore Insert
- Regular price
- $33.35 ex VAT
- Sale price
- $33.35
- Regular price
-
In stock
Quantity Price Breaks
10+
$29.68
19+
$28.01
29+
$27.68
39+
$27.35
49+
$27.01
74+
$26.68
99+
$25.01
199+
$24.68
249+
$24.35
499+
$24.01
999+
$23.35
SKU:
UCHA207-21
UCHA207-21 Imperial Cast Iron Hanger Bearing Unit with 1-5/16 inch Bore Insert
- Regular price
- $33.35 ex VAT
- Sale price
- $33.35
- Regular price
-
Description
UCHA200 Series Normal Duty Screw Conveyor Hanger Units: These bearing units are supplied with a fully sealed bearing insert fitted and includes a grease nipple to facilitate lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts can be removed from the housing for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
Technical
| d | = | 1-5/16 inch |
| h | = | 2-3/4 inch |
| w | = | 4-9/16 inch |
| b | = | 3-5/8 inch |
| c | = | 0 inch |
| a | = | 1-37/64 inch |
| s | = | G-3/4 |
| l | = | 3/4 inch |
| B | = | 1.689 inch |
| n | = | 0.689 inch |
| Bearing no | = | UC207-21 |
| Housing no | = | HA207 |
| Weight | = | 1.134 kg |
