SKU: UCFX15-215D1-NTN
NTN UCFX15-215D1 Imperial Four Bolt Square Cast Iron Flange Housing with 2-15/16 inch Bore Insert - Allow 2-3 Days
- Regular price
- $182.63 ex VAT
- Sale price
- $182.63
- Regular price
-
In stock
Quantity Price Breaks
10+
$162.54
19+
$153.41
29+
$151.58
39+
$149.76
49+
$147.93
74+
$146.10
99+
$136.97
199+
$135.15
249+
$133.32
499+
$131.49
999+
$127.84
SKU:
UCFX15-215D1-NTN
NTN UCFX15-215D1 Imperial Four Bolt Square Cast Iron Flange Housing with 2-15/16 inch Bore Insert - Allow 2-3 Days
- Regular price
- $182.63 ex VAT
- Sale price
- $182.63
- Regular price
-
Description
|
UCFX or MSF Series 4 Bolt Square Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| --- | = | Dimensions |
| Shaft diameter | = | 2-15/16 inch |
| L | = | 7-3/4 inch |
| J | = | 5-63/64 inch |
| A< | = | sub> |
| 2< | = | /sub> |
| = | 1-37/64 inch | |
| A< | = | sub> |
| 1< | = | /sub> |
| = | 15/16 inch | |
| A | = | 2-11/16 inch |
| N | = | 29/32 inch |
| A< | = | sub> |
| 0< | = | /sub> |
| = | 3-33/64 inch | |
| B | = | 3.252 inch |
| S | = | 1.311 inch |
| Fixing bolt | = | 3/4 inch |
| --- | = | Load rating |
| Dynamic load C< | = | sub> |
| r< | = | /sub> |
| = | 80.5 kN | |
| Static load C< | = | sub> |
| 0r< | = | /sub> |
| = | 53 kN | |
| Fatigue load limit C< | = | sub> |
| u< | = | /sub> |
| = | 3.95 kN | |
| --- | = | Unit information |
| Mass | = | 19 lbs |
