SKU: UCFX14D1-NTN
NTN UCFX14D1 Metric Four Bolt Square Cast Iron Flange Housing with 70mm Bore Insert - Allow 2-3 Days
- Regular price
- $158.14 ex VAT
- Sale price
- $158.14
- Regular price
-
In stock
Quantity Price Breaks
10+
$140.74
19+
$132.84
29+
$131.26
39+
$129.67
49+
$128.09
74+
$126.51
99+
$118.61
199+
$117.02
249+
$115.44
499+
$113.86
999+
$110.70
SKU:
UCFX14D1-NTN
NTN UCFX14D1 Metric Four Bolt Square Cast Iron Flange Housing with 70mm Bore Insert - Allow 2-3 Days
- Regular price
- $158.14 ex VAT
- Sale price
- $158.14
- Regular price
-
Description
|
UCFX or MSF Series 4 Bolt Square Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| --- | = | Dimensions |
| Shaft diameter | = | 70mm |
| L | = | 197mm |
| J | = | 152mm |
| A< | = | sub> |
| 2< | = | /sub> |
| = | 37mm | |
| A< | = | sub> |
| 1< | = | /sub> |
| = | 24mm | |
| A | = | 60mm |
| N | = | 23mm |
| A< | = | sub> |
| 0< | = | /sub> |
| = | 81.5mm | |
| B | = | 77.8mm |
| S | = | 33.3mm |
| Fixing bolt | = | M20 |
| --- | = | Load rating |
| Dynamic load C< | = | sub> |
| r< | = | /sub> |
| = | 73.5 kN | |
| Static load C< | = | sub> |
| 0r< | = | /sub> |
| = | 49.5 kN | |
| Fatigue load limit C< | = | sub> |
| u< | = | /sub> |
| = | 3.8 kN | |
| --- | = | Unit information |
| Mass | = | 7.1 kg |
