SKU: UCFX11D1-NTN
NTN UCFX11D1 Metric Four Bolt Square Cast Iron Flange Housing with 55mm Bore Insert - Allow 2-3 Days
- Regular price
- $93.10 ex VAT
- Sale price
- $93.10
- Regular price
-
In stock
Quantity Price Breaks
10+
$82.86
19+
$78.20
29+
$77.27
39+
$76.34
49+
$75.41
74+
$74.48
99+
$69.83
199+
$68.89
249+
$67.96
499+
$67.03
999+
$65.17
SKU:
UCFX11D1-NTN
NTN UCFX11D1 Metric Four Bolt Square Cast Iron Flange Housing with 55mm Bore Insert - Allow 2-3 Days
- Regular price
- $93.10 ex VAT
- Sale price
- $93.10
- Regular price
-
Description
|
UCFX or MSF Series 4 Bolt Square Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| --- | = | Dimensions |
| Shaft diameter | = | 55mm |
| L | = | 175mm |
| J | = | 143mm |
| A< | = | sub> |
| 2< | = | /sub> |
| = | 29mm | |
| A< | = | sub> |
| 1< | = | /sub> |
| = | 20mm | |
| A | = | 49mm |
| N | = | 19mm |
| A< | = | sub> |
| 0< | = | /sub> |
| = | 68.7mm | |
| B | = | 65.1mm |
| S | = | 25.4mm |
| Fixing bolt | = | M16 |
| --- | = | Load rating |
| Dynamic load C< | = | sub> |
| r< | = | /sub> |
| = | 58 kN | |
| Static load C< | = | sub> |
| 0r< | = | /sub> |
| = | 36 kN | |
| Fatigue load limit C< | = | sub> |
| u< | = | /sub> |
| = | 2.83 kN | |
| --- | = | Unit information |
| Mass | = | 4.8 kg |
