SKU: UCFCX15D1-NTN
NTN UCFCX15D1 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert - Allow 2-3 Days
- Regular price
- $167.05 ex VAT
- Sale price
- $167.05
- Regular price
-
In stock
Quantity Price Breaks
10+
$148.67
19+
$140.32
29+
$138.65
39+
$136.98
49+
$135.31
74+
$133.64
99+
$125.29
199+
$123.62
249+
$121.95
499+
$120.28
999+
$116.94
SKU:
UCFCX15D1-NTN
NTN UCFCX15D1 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert - Allow 2-3 Days
- Regular price
- $167.05 ex VAT
- Sale price
- $167.05
- Regular price
-
Description
UCFCX Series Medium Duty 4 Bolt Round Housings: These medium-duty bearing units are supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
Technical
| --- | = | Dimensions |
| Shaft diameter | = | 75mm |
| L | = | 222mm |
| J | = | 190mm |
| (J< | = | sub> |
| 1< | = | /sub> |
| ) | = | 134.4mm |
| A< | = | sub> |
| 2< | = | /sub> |
| = | 12mm | |
| N | = | 19mm |
| A< | = | sub> |
| 3< | = | /sub> |
| = | 22mm | |
| A< | = | sub> |
| 1< | = | /sub> |
| = | 35mm | |
| A | = | 57mm |
| H< | = | sub> |
| 3< | = | /sub> |
| = | 164mm | |
| A< | = | sub> |
| 0< | = | /sub> |
| = | 83.3mm | |
| B | = | 82.6mm |
| S | = | 33.3mm |
| F (Min.) | = | 105mm |
| Fixing bolt | = | M16 |
| --- | = | Load rating |
| Dynamic load C< | = | sub> |
| r< | = | /sub> |
| = | 80.5 kN | |
| Static load C< | = | sub> |
| 0r< | = | /sub> |
| = | 53 kN | |
| Fatigue load limit C< | = | sub> |
| u< | = | /sub> |
| = | 3.95 kN | |
| --- | = | Unit information |
| Mass | = | 8 kg |
