SKU: UCFCX09D1-NTN
NTN UCFCX09D1 Metric Four Bolt Cast Iron Round Flanged Housing with 45mm Insert - Allow 2-3 Days
- Regular price
- $72.16 ex VAT
- Sale price
- $72.16
- Regular price
-
In stock
Quantity Price Breaks
10+
$64.22
19+
$60.61
29+
$59.89
39+
$59.17
49+
$58.45
74+
$57.73
99+
$54.12
199+
$53.40
249+
$52.68
499+
$51.96
999+
$50.51
SKU:
UCFCX09D1-NTN
NTN UCFCX09D1 Metric Four Bolt Cast Iron Round Flanged Housing with 45mm Insert - Allow 2-3 Days
- Regular price
- $72.16 ex VAT
- Sale price
- $72.16
- Regular price
-
Description
UCFCX Series Medium Duty 4 Bolt Round Housings: These medium-duty bearing units are supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
Technical
| --- | = | Dimensions |
| Shaft diameter | = | 45mm |
| L | = | 155mm |
| J | = | 130mm |
| (J< | = | sub> |
| 1< | = | /sub> |
| ) | = | 91.9mm |
| A< | = | sub> |
| 2< | = | /sub> |
| = | 8mm | |
| N | = | 14mm |
| A< | = | sub> |
| 3< | = | /sub> |
| = | 12mm | |
| A< | = | sub> |
| 1< | = | /sub> |
| = | 25mm | |
| A | = | 37mm |
| H< | = | sub> |
| 3< | = | /sub> |
| = | 108mm | |
| A< | = | sub> |
| 0< | = | /sub> |
| = | 52.6mm | |
| B | = | 51.6mm |
| S | = | 19mm |
| F (Min.) | = | 68mm |
| Fixing bolt | = | M12 |
| --- | = | Load rating |
| Dynamic load C< | = | sub> |
| r< | = | /sub> |
| = | 39 kN | |
| Static load C< | = | sub> |
| 0r< | = | /sub> |
| = | 23.2 kN | |
| Fatigue load limit C< | = | sub> |
| u< | = | /sub> |
| = | 1.82 kN | |
| --- | = | Unit information |
| Mass | = | 2.6 kg |
