SKU: UCF328-SNR
SNR UCF328 Metric Four Bolt Square Cast Iron Flange Housing with 140mm Bore Insert - Allow 2-3 Days
- Regular price
- $1,509.62 ex VAT
- Sale price
- $1,509.62
- Regular price
-
In stock
Quantity Price Breaks
10+
$1,343.56
19+
$1,268.08
29+
$1,252.98
39+
$1,237.89
49+
$1,222.79
74+
$1,207.70
99+
$1,132.22
199+
$1,117.12
249+
$1,102.02
499+
$1,086.93
999+
$1,056.73
SKU:
UCF328-SNR
SNR UCF328 Metric Four Bolt Square Cast Iron Flange Housing with 140mm Bore Insert - Allow 2-3 Days
- Regular price
- $1,509.62 ex VAT
- Sale price
- $1,509.62
- Regular price
-
Description
|
UCF or SF Series 4 Bolt Square Cast Iron Housings: Bearing units supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| --- | = | Dimensions |
| Shaft diameter d | = | 140mm |
| A | = | 125mm |
| A1 | = | 55mm |
| A2 | = | 161mm |
| B | = | 145mm |
| e | = | 75mm |
| J | = | 350mm |
| L | = | 450mm |
| N | = | 41mm |
| S | = | 59mm |
| G | = | M10x1 |
| --- | = | Load rating |
| Dynamic load C | = | 275 kN |
| Static load C0 | = | 272 kN |
| --- | = | Unit information |
| Operating temperature min. | = | -20& |
| deg | = | C |
| Operating temperature max. | = | 100& |
| deg | = | C |
| Recommended tightening torque for set screw | = | 120 Nm |
| Mass | = | 83.88 kg |
