SKU: UCF208N-SNR
SNR UCF208N Metric Four Bolt Square Cast Iron Flange Housing with 40mm Bore Insert - Allow 2-3 Days
- Regular price
- $51.90 ex VAT
- Sale price
- $51.90
- Regular price
-
In stock
Quantity Price Breaks
10+
$46.19
19+
$43.60
29+
$43.08
39+
$42.56
49+
$42.04
74+
$41.52
99+
$38.93
199+
$38.41
249+
$37.89
499+
$37.37
999+
$36.33
SKU:
UCF208N-SNR
SNR UCF208N Metric Four Bolt Square Cast Iron Flange Housing with 40mm Bore Insert - Allow 2-3 Days
- Regular price
- $51.90 ex VAT
- Sale price
- $51.90
- Regular price
-
Description
|
UCF or SF Series 4 Bolt Square Cast Iron Housings: Bearing units supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| --- | = | Dimensions |
| Shaft diameter d | = | 40mm |
| A | = | 36mm |
| A1 | = | 15mm |
| A2 | = | 51.2mm |
| B | = | 49.2mm |
| e | = | 21mm |
| J | = | 102mm |
| L | = | 130mm |
| N | = | 16mm |
| S | = | 19mm |
| G | = | M6x1 |
| --- | = | Load rating |
| Dynamic load C | = | 29.6 kN |
| Static load C0 | = | 18.2 kN |
| --- | = | Unit information |
| Operating temperature min. | = | -20& |
| deg | = | C |
| Operating temperature max. | = | 100& |
| deg | = | C |
| Recommended tightening torque for set screw | = | 11.5 Nm |
| Mass | = | 1.89 kg |
