SKU: SSUCF.211-32
SSUCF211-32 Imperial Four Bolt Square Stainless Steel Flange Housing with 2 inch Bore Stainless Insert
- Regular price
- $147.06 ex VAT
- Sale price
- $147.06
- Regular price
-
Not in stock
Quantity Price Breaks
3
$130.88
4
$123.53
9
$122.06
19
$120.59
49
$119.12
99
$117.65
499
$110.30
999
$108.82
1999
$107.35
2999
$105.88
4999
$102.94
SKU:
SSUCF.211-32
SSUCF211-32 Imperial Four Bolt Square Stainless Steel Flange Housing with 2 inch Bore Stainless Insert
- Regular price
- $147.06 ex VAT
- Sale price
- $147.06
- Regular price
-
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Technical
| d | = | 2 inch |
| a | = | 162mm |
| e | = | 130mm |
| i | = | 25mm |
| g | = | 20mm |
| L | = | 43mm |
| S | = | 19mm |
| Z | = | 58.4mm |
| Bi | = | 55.6mm |
| n | = | 22.2mm |
| Bolt | = | 16mm |
| Weight | = | 3.4 kg |
| Dynamic load | = | 3400 kgf |
| Static load | = | 2550 kgf |
