SKU: SSUCF.206-18
SSUCF206-18 Imperial Four Bolt Square Stainless Steel Flange Housing with 1-1/8 inch Bore Stainless Insert
- Regular price
- $103.97 ex VAT
- Sale price
- $103.97
- Regular price
-
ex VAT
In stock
Quantity Price Breaks
3
$92.53
4
$87.33
9
$86.30
19
$85.26
49
$84.22
99
$83.18
499
$77.98
999
$76.94
1999
$75.90
2999
$74.86
4999
$72.78
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Technical
| d | = | 1-1/8 inch |
| a | = | 108mm |
| e | = | 83mm |
| i | = | 18mm |
| g | = | 14mm |
| L | = | 31mm |
| S | = | 12mm |
| Z | = | 40.2mm |
| Bi | = | 38.1mm |
| n | = | 15.9mm |
| Bolt | = | 10mm |
| Weight | = | 1.1 kg |
| Dynamic load | = | 1520 kgf |
| Static load | = | 1020 kgf |
