SKU: SBLF.207-22
SBLF207-22 Imperial Two Bolt Cast Iron Oval Housing with 1-3/8 inch Bore Grub Screw Insert
- Regular price
- $22.32 ex VAT
- Sale price
- $22.32
- Regular price
-
In stock
Quantity Price Breaks
10+
$19.86
19+
$18.75
29+
$18.53
39+
$18.30
49+
$18.08
74+
$17.86
99+
$16.74
199+
$16.52
249+
$16.29
499+
$16.07
999+
$15.62
SKU:
SBLF.207-22
SBLF207-22 Imperial Two Bolt Cast Iron Oval Housing with 1-3/8 inch Bore Grub Screw Insert
- Regular price
- $22.32 ex VAT
- Sale price
- $22.32
- Regular price
-
Description
|
SBLF Series 2 Bolt Oval Cast Iron Housings: Normal duty bearing unit supplied with a fully sealed flat back bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted.
The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, Re-lubricateable, replaceable insert, grub screw fixing, flat back of bearing |
Technical
| d | = | 1-3/8 inch |
| a | = | 122mm |
| e | = | 100mm |
| b | = | 89mm |
| i | = | 13mm |
| s | = | 12mm |
| g | = | 13mm |
| l | = | 24mm |
| Bolt | = | M10 |
| z | = | 36.5mm |
| n | = | 8.5mm |
| Weight | = | 0.9 kg |
| Dynamic load | = | 2010 kgf |
| Static load | = | 1390 kgf |
