SKU: MFC3-RHP
RHP MFC3 Four Bolt Round Cast Iron Flanged Bearing Unit and 3 inch Insert
- Regular price
- $426.39 ex VAT
- Sale price
- $426.39
- Regular price
-
In stock
Quantity Price Breaks
10+
$379.49
19+
$358.17
29+
$353.90
39+
$349.64
49+
$345.38
74+
$341.11
99+
$319.79
199+
$315.53
249+
$311.26
499+
$307.00
999+
$298.47
SKU:
MFC3-RHP
RHP MFC3 Four Bolt Round Cast Iron Flanged Bearing Unit and 3 inch Insert
- Regular price
- $426.39 ex VAT
- Sale price
- $426.39
- Regular price
-
Description
|
RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
Technical
| Bore | = | 3 inch |
| L | = | 8.748 inch |
| H | = | 6.375 inch |
| J | = | 7.5 inch |
| G | = | 0.625 inch |
| A1 | = | 2 inch |
| A4 | = | 0.657 inch |
| A5 | = | 0.5 inch |
| B | = | 3.25 inch |
| s | = | 1.314 inch |
| d1 | = | 3.878 inch |
| Dynamic load | = | 71500 N |
| Static load | = | 54500 N |
| Rec max speed | = | 2150 rpm |
| Weight | = | 5.4 kg |
| Insert | = | < |
| a href=" | = | advanced_search_result.php?keywords=1080-3G+insonly" |
| > | = | 1080-3G Click Here< |
| /a> | = | |
| Casting group | = | 9 |
| Grease nipple thread | = | 1/4 UNF, 1/4 inch x 28 TPI |
