SKU: FYTJ45KF-SKF
SKF FYTJ45KF Flanged Unit with an Oval Cast Housing with 40mm Insert
- Regular price
- $122.31 ex VAT
- Sale price
- $122.31
- Regular price
-
In stock
Quantity Price Breaks
10+
$108.86
19+
$102.74
29+
$101.52
39+
$100.29
49+
$99.07
74+
$97.85
99+
$91.73
199+
$90.51
249+
$89.29
499+
$88.06
999+
$85.62
SKU:
FYTJ45KF-SKF
SKF FYTJ45KF Flanged Unit with an Oval Cast Housing with 40mm Insert
- Regular price
- $122.31 ex VAT
- Sale price
- $122.31
- Regular price
-
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing and Adapter Sleeve: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Note: The appropriate adapter sleeve is not part of the bearing and must be ordered separately. Benefits: Grease fitting allows re-lubrication |
Technical
| d | = | 40mm |
| A1 | = | 36mm |
| A2 | = | 18mm |
| B1 | = | 50mm |
| Da | = | 98.4mm |
| H | = | 188mm |
| J | = | 148mm |
| L | = | 108mm |
| N | = | 19mm |
| G | = | 16mm |
| s1 | = | 28.5mm |
| T | = | 50.5mm |
| Static load Cr | = | 21.6 kN |
| Dynamic load Cor | = | 33.2 kN |
| Fatigue load limit Pu | = | 0.915 kN |
| Limiting speed | = | 4300 rpm |
| Weight | = | 2.2 kg |
