SKF FYTJ35KF Flanged Unit with an Oval Cast Housing with 30mm Insert
- Regular price
- $92.75 ex VAT
- Sale price
- $92.75
- Regular price
-
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing and Adapter Sleeve: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Note: The appropriate adapter sleeve is not part of the bearing and must be ordered separately. Benefits: Grease fitting allows re-lubrication |
Technical
| d | = | 30mm |
| A1 | = | 34mm |
| A2 | = | 16mm |
| B1 | = | 43mm |
| Da | = | 88.9mm |
| H | = | 161mm |
| J | = | 130mm |
| L | = | 96mm |
| N | = | 16mm |
| G | = | 14mm |
| s1 | = | 24.3mm |
| T | = | 43.3mm |
| Static load Cr | = | 15.3 kN |
| Dynamic load Cor | = | 25.5 kN |
| Fatigue load limit Pu | = | 0.655 kN |
| Limiting speed | = | 5300 rpm |
| Weight | = | 1.3 kg |
