SKU: FYT1.3/4FM-SKF
SKF FYT1-3/4FM Oval Cast Housing with Grub Screw 1-3/4 inch Insert
- Regular price
- $84.00 ex VAT
- Sale price
- $84.00
- Regular price
-
In stock
Quantity Price Breaks
10+
$74.76
19+
$70.56
29+
$69.72
39+
$68.88
49+
$68.04
74+
$67.20
99+
$63.00
199+
$62.16
249+
$61.32
499+
$60.48
999+
$58.80
SKU:
FYT1.3/4FM-SKF
SKF FYT1-3/4FM Oval Cast Housing with Grub Screw 1-3/4 inch Insert
- Regular price
- $84.00 ex VAT
- Sale price
- $84.00
- Regular price
-
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing and Grub Screws: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Benefits: Grease fitting allows re-lubrication |
Technical
| d | = | 1-3/4 inch |
| A1 | = | 39mm |
| A2 | = | 34mm |
| B1 | = | 43.7mm |
| H | = | 178.5mm |
| J | = | 348.4mm |
| L | = | 333mm |
| N | = | 35.9mm |
| G | = | 34mm |
| s1 | = | 32.7mm |
| T | = | 56.7mm |
| Static load Cr | = | 21.6 kN |
| Dynamic load Cor | = | 33.2 kN |
| Fatigue load limit | = | 0.915 kN |
| Limiting speed | = | 4300 rpm |
| Weight | = | 1.85 kg |
| Housing | = | |
| Insert | = |
