SKU: ASFD206-NTN
NTN ASFD206 Metric Two Bolt Oval Cast Iron Flange Housing with 30mm Bore Insert - Allow 2-3 Days
- Regular price
- $42.32 ex VAT
- Sale price
- $42.32
- Regular price
-
In stock
Quantity Price Breaks
10+
$37.66
19+
$35.55
29+
$35.13
39+
$34.70
49+
$34.28
74+
$33.86
99+
$31.74
199+
$31.32
249+
$30.89
499+
$30.47
999+
$29.62
SKU:
ASFD206-NTN
NTN ASFD206 Metric Two Bolt Oval Cast Iron Flange Housing with 30mm Bore Insert - Allow 2-3 Days
- Regular price
- $42.32 ex VAT
- Sale price
- $42.32
- Regular price
-
Description
ASFD200 Series 2 Bolt Cast Iron Oval Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the housing and include a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
Technical
| Shaft diameter | = | 30mm |
| H | = | 113mm |
| J | = | 90mm |
| A< | = | sub> |
| 2< | = | /sub> |
| = | 12mm | |
| A | = | 21mm |
| N | = | 12mm |
| L | = | 84mm |
| A< | = | sub> |
| 0< | = | /sub> |
| = | 33mm | |
| B | = | 29mm |
| S | = | 8mm |
| Fixing bolt | = | M10 |
| Mass | = | 0.8 kg |
