SKU: 32208.JR.KOY
KOYO 32208JR Taper Roller Bearing 40x80x24.75mm
- Regular price
- $29.00 ex VAT
- Sale price
- $29.00
- Regular price
-
In stock
Quantity Price Breaks
10
$25.81
20
$24.36
30
$24.07
40
$23.78
50
$23.49
75
$23.20
100
$21.75
200
$21.46
250
$21.17
500
$20.88
1000
$20.30
SKU:
32208.JR.KOY
KOYO 32208JR Taper Roller Bearing 40x80x24.75mm
- Regular price
- $29.00 ex VAT
- Sale price
- $29.00
- Regular price
-
Description
|
Narrow Section Taper Roller Bearings: Typically used in motorcycle steering heads these bearings are manufactured with large bore to outside diameter ratios and low overall height to permit use in space restricted applications, typically in motorcycle and automotive installations Benefits: Narrow section, low height, large bore to diameter ratio |
Technical
| d | = | 40mm |
| D | = | 80mm |
| T | = | 24.75mm |
| B | = | 23mm |
| C | = | 19mm |
| r min | = | 1.5mm |
| r1 min | = | 1.5mm |
| Dynamic load Cr | = | 77.5 kN |
| Static load Cor | = | 90.8 kN |
| Speed in grease | = | 5000 rpm |
| Speed in oil | = | 6600 rpm |
| a | = | 19.4mm |
| da min | = | 48.5mm |
| db max | = | 48mm |
| Da max | = | 71.5mm |
| Da min | = | 68mm |
| Db min | = | 75mm |
| Ca min | = | 3mm |
| Cb min | = | 5.5mm |
| ra max | = | 1.5mm |
| rb max | = | 1.5mm |
| e | = | 0.37 |
| Y1 | = | 1.6 |
| Y0 | = | 1.14 |
| Mass | = | 0.133 kg |
