305802C2Z Budget Crowned Double Row Cam Roller Bearing 15x40x15.9mm

SKU: 305802C-2Z-EU

305802C2Z Budget Crowned Double Row Cam Roller Bearing 15x40x15.9mm

$25.76 ex VAT
$25.76
ex VAT
In stock

Quantity Price Breaks

10 $22.93
19 $21.64
29 $21.38
39 $21.12
49 $20.87
74 $20.61
99 $19.32
199 $19.06
249 $18.80
499 $18.55
999 $18.03
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
305802C2Z Budget Crowned Double Row Cam Roller Bearing 15x40x15.9mm
SKU: 305802C-2Z-EU

305802C2Z Budget Crowned Double Row Cam Roller Bearing 15x40x15.9mm

$25.76 ex VAT
$25.76
ex VAT

Description

Double Row Cam Rollers: Are special variants of deep groove ball bearings which have thicker outer races to allow for running in tracks as rollers where misalignment and shock loads may be present. They have the same characteristics as normal deep groove ball bearings, generally have seals although some unsealed versions are available and can also be used in place of standard bearings. They are available with parallel outside diameter or crowned (spherical) for applications where greater misalignment needs to be catered for.
Benefits: Tolerate high loads, shock loads, misalignment when running in tracks

Technical

d = 15mm
D = 40mm
B = 15.9mm
d1 = 22.1mm
D1 = 30.7mm
r1r2 min = 0.6mm
a = 18mm
Limiting speed = 8500 rpm
Weight = 0.1 kg
Dynamic load C = 10.6 kN
Static load Co = 5.85 kN
Fatigue load limit Pu = 0.25 kN
Maximum dynamic radial load Fr = 5.85 kN
Maximum static radial load For = 8.5 kN
